74,000 LB. ALI Certified Battery Powered Mobile Column Lift System

Call for Price

  • ALI CERTIFIED
  • Simultaneous operation of all columns
  • LCD screen shows exact lifting height of each column
  • Electronic system ensuring synchronization of all columns
  • Double-safety guaranteed by both hydraulic flow control and mechanical locks
  • Portable columns make your work easy and comfortable
  • Can be “Expanded” from a four (74,000 lb. capacity) column system to a six (111,000 lb. capacity) or eight (148,000 lb. capacity) column system
  • Adjustable forks can accommodate tire diameters from 19 inches to 44 inches
  • Emergency stop button on every column
  • Four 32' column connecting cables included
  • 2.2 Kw 24V DC motor with two batteries per column
  • 2 Year Limited Warranty
  • Lifting capacity per column: 18,500
  • Weight per column: 1,700 lbs
  • Shipping Weight (for four columns): 6800 lbs

How to Purchase

Description

The ALI CERTIFIED 74,000 lb. capacity Atlas® battery powered, four (4) piece mobile column lift system (ML-4034BC) is now available. This 24V DC motor and battery powered system works anywhere. It is not dependent on a wall socket. The Atlas® mobile column lift system is designed and engineered for bus, RV, and truck lifting applications that require high quality and reliability.

The Atlas® mobile column lift system is the perfect choice for any repair shop that needs to safely raise those heavier trucks but has limited bay space. Each heavy duty mobile column is DC motor powered and equipped with a pair of rechargeable batteries. This, coupled with the hydraulic pallet jack system on each column, allows for unparalleled freedom of movement. The columns may even be moved outside for use on a level concrete surface with a minimum thickness of six (6) inches. The mobile columns can be easily stored out of the way when not in use.

Atlas® 74,000 LB. Battery Powered Mobile Column Lift System Specifications
Capacity per Column 18,500 LB.
Motor 2.2 Kw 24V DC motor with two batteries per column
Max. Lifting Height 67″ (5′ 7″)
Overall Height 145″ (12′ 1″)
Resting Height 88 1/2″ (7′ 4 1/2″)
Width 43 1/2″ (3′ 7 1/2″)
Length 55 1/2″ (4′ 7 1/2″)
Column Width 13 1/4″
Warranty 2 Year Limited
Shipping Weight (For Four Columns) 6,800 LB. each
Shipping Weight Per Column 1,700 LB. each
Max Tire Diameter 44″
Min Tired Diameter 19″
